Concealed Hinge, TECTUS TE 240 3D

$162.26
$162.26
Sale Sold out
Shipping calculated at checkout.

*Free Standard Ground Shipping on Orders over $199

  • Mounting: For DIN left and DIN right hand use
  • Flange shape: rounded
  • Flange width: 21 mm / 18 mm
  • Material: Aluminum, Steel
  • Model: TE 240 3D N
  • Flange height: 155 mm
  • Door weight max.: 132 lbs
  • Door thickness min.: 1"
  • Model series : TECTUS
  • Area of application :

    Used in door frames made out of hollow metal or wood for flush doors

  • For frame type : Steel frame, Wooden frame, Aluminum frame
  • Max. door weight for 2 hinges : 60 kg
  • Opening angle : 180 °
  • Door thickness : ≥25 mm
  • Router bit Ø : 16 mm
  • Router bit Ø : 5/8”; Guide: 1 3/16"
  • Thrust ring Ø : 30 mm
  • Bearing type : Friction bearing, maintenance-free
  • Adjustment facility : 3D Continuous, Side: ±3 mm, Height: ±3 mm, Closing pressure: ±1.5 mm
  • Standard : Certified in compliance with EN 1935:2002
  • Grade : 2|7|2|0|1|3|0|7
  • Order reference :

    “Energy” version for permanent and invisible energy transmission from the door frame to the door leaf optionally available
