• Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set
1 8

Sliding door fitting, Hawa Libra 20 Synchro H IF/VF, set

$739.73
$739.73
Sale Sold out
Shipping calculated at checkout.

*Free Standard Ground Shipping on Orders over $199

  • Number of doors: 2
  • For door thickness: ≥16 mm
  • For door width: ≤1,600 mm
  • For door weight: ≤20 kg
  • Running position: bottom, top on the side
  • Number of rollers: 1
  • For side panel thickness: min 16 mm
  • For door material: wood
  • Door width max.: Max. 63"
  • For door thickness min.: 5/8"
  • Side panel thickness min.: 5/8"
  • Cabinet version : with synchronized running doors
  • Model series : Libra
  • Set : Set without tracks
  • Area of application :

    For 2 doors

  • For door height : ≤1,000 mm
  • Material/finish : Rollers: Plastic
  • Installation : Running gear and guide for screw fixing
  • Counterweight : The bottom door represents the counterweight for the top door, therefore both doors must be of equal weight
  • Type of opening : linear
  • Number of doors per system max. : 2
  • Order reference :

    In general, doors should be the same size, and must weigh the same as they need to counter balance each other

  • Supplied with :

    4 sliding hardware with cam adjustment
    4 sliding hardware with spring
    2 reverse roller
    2 door safety
    4 rope brackets
    2 tightening bolt for rope bracket
    2 pcs of rope
    2 cover caps
    8 covers for sliding hardware
