• Concealed Hinge, Grass, Tiomos M9 110°, for Thin Doors
1 6

Concealed Hinge, Grass, Tiomos M9 110°, for Thin Doors

$29.32
$29.32
Sale Sold out
Shipping calculated at checkout.

*Free Standard Ground Shipping on Orders over $199

  • Low cup depth 9 mm
    Door overlay up to 25 mm
    With integrated, adjustable soft closing mechanism with 3 settings or with opening mechanism

  • Accommodates overlays up to 25mm (1”)
    For door thicknesses from 12 mm (1/2”) to 28 mm (1 1/8”)
    Soft close hinges
    Shallow cup depth of 9mm

  • Version: With automatic closing spring
  • Drilling pattern: 45/9,5
  • Cup fixing: for screw fixing
  • Color/finish: Nickel plated
  • Mounting: mounting in drilled hole, screw fixing
  • Model: -
  • Model series : M9
  • For door material : wood
  • Concealed hinge version : miter
  • Crank type : Cranked
  • Opening angle : 110 °
  • Suitable for :

    Thin doors from 12 mm thick, rebated doors and surrounding mitre

  • Material : Zinc alloy, Hinge arm: Zinc alloy
  • Installation :

    For screw fixing to door

  • Door processing for assembly : cup drilling
  • Adjustment facility : Side adjustment facility: ±2 mm, Height adjustment facility: ±2.5 mm, Depth adjustment facility: -2 – 3 mm, Height adjustment depending on mounting plate
  • For wooden door thickness : 12 – 28 mm
  • Cup drilling depth : 9 mm
